Hand measuring station for part length measurement

Test station for the final length measurement of profiles, pipes, hoses

If discrete part lengths are to be measured quickly and reliably and the measurement length has to be documented, the use of the ELOVIS length-section light scanner is also suitable for the design of manual test stations. Whether for monitoring the cutting unit or for determining the material shrinkage after extrusion, by the ELOVIS SLM gauge measurement is carried out quickly and safely and a 100% documentation of the measurement values is ensured.

Typical application data:

  • Measurement of profiles after cutting, before packaging
  • Measurement of part lengths to determine shrinkage and shrinkage factors
  • Problem with contacting measuring instruments: Accuracy: +/- 1mm/m; operator dependent
  • Measurement accuracy with non-contact length measurement SLM: typically 0,1mm / m
  • Amortization: 3 months, mobile testing station for use in different positions

Material examples:

  • Extruded profiles of hard and soft plastic as well as co-extrusion and tri-extrusion
  • Materials: PVC, ABS, PP, PC, PMMA, ASA and TPU
  • Products: Sealing profiles, pipes, hoses, corrugated pipes, windscreen wiper profiles, spoilers, …

Machines which are extended by a non-contact hand testing station:

  • guillotine, cross cutter, cross divider, cutting machine
  • saw line, flying saw, continuous saw, punch
  • Packaging lines, sorting lines, QS stations

Matching Products and Services

Length-Section Light Scanner
Discrete Part Length Measurement System

  • Non-contact length measurement of discrete parts in the production process or in a cycle
  • Highly accurate measurement of discrete parts, good/bad sorting and documentation
  • LED-based length-section light scanner measurement technology, maintenance-free, optical, permanently calibrated
  • Optical micrometer for the length measurement of profiles, tubes, plates

ELOVIS Services

ELOVIS offers the following services for measuring piece lengths:

  • Advice on piece length measurement
  • measurement services
  • Help with length complaints of your customers
  • OEM sensor developments in the area of piece length measurement
