Roll Cutter for Roof Sheeting

Non-Contact, surface-independent measurement of Bituminous sheeting.

Due to the large number of different measuring surfaces, the CTL length cutting of sales rolls of roofing membranes, bituminous foil and flat roof sheeting can only be permanently accurate with non-contact length measurement systems. Sanded surfaces or very smooth, foiled surfaces quickly push friction wheel-based measurement systems to their limits. Reliability, accuracy and longevity in length measurement are achieved with non-contact μSPEED laser encoders.

Typical application data:

  • Cutting of roof sheeting sales rollers with lengths between 5 and 50m
  • Path Velocity: typically up to 400 m / min
  • Measurement accuracy with tactile measuring equipment or via drive: typically 1 – 5%
  • Measurement accuracy with non-contact length measurement μSPEED: typically 0.05%
  • Amortization: 1-2 months, direct encoder replacement, no other modifications needed

Material examples:

  • Bituminous sheeting, sanded, laminated, self-adhesive, structured
  • roof sheeting, flat roof foils, sealing membranes, roof welding membranes, …

Machines equipped with non-contact length measurement:

  • Roll cutting machine, roll cutter, cross cutter, lengthwise cutter
  • Winding machines, rewinder, re-roller, doctor roller
  • extruders, film casting machines, calenders
  • laminators, laminating machine

Matching Products and Services

Length & Speed Measurement Systems

  • Non-contact length and speed measurement, optically by laser
  • Length and speed free of slippage, maintenance-free, permanently calibrated and accurately measured
  • The Laser-Encoder replaces tactile measurement via impeller, wheel, measurement roller, or machine drive
  • Measurement of agitated surfaces via laser-doppler surface velocimeter

ELOVIS Services

ELOVIS offers the following services for the measurement of films:

  • Advice on length and speed measurement
  • Measurement & calibration services
  • Help with length complaints of your customers
  • OEM sensor developments in the field of length and speed measurement
